110V Extension Lead 14m 4mm Cable 32A – (10826)
Product Features:
- Cable Length: 14m
- Cable Thickness: 4.00mm
- Voltage: 110V
- Connections: 32A Plug and Coupler
Browse our full range of 110V extension leads, or add one of our 110V cable reels for longer runs.
14m 110V 32A site extension lead
The Connexion 10826 is a yellow 14m 110V extension lead with 4.0mm² 3-core PVC cable, a 32A 110V plug and a 32A 110V coupler. The 4mm conductor is the heaviest gauge in our 14m range.
On UK construction sites, portable tools and lighting normally run on 110V supplied by a centre-tapped-to-earth site transformer, and 110V industrial connectors are colour-coded yellow under BS EN 60309.
Key features and specifications
| Part number | 10826 |
|---|---|
| Voltage | 110V |
| Cable length | 14m |
| Cable size | 4.0mm² 3-core PVC |
| Plug | 32A 110V |
| Coupler | 32A 110V |
| Colour | Yellow |
| IP rating | IP44 |
| Safety class | Class I |
| Frequency | 50/60Hz |
| Maximum current | 32A |
| Construction | PVC/copper cable, nylon + PP plug |
Applications
Heavy 32A 110V runs to splitter boxes and high-current site equipment where minimising voltage drop matters.
Choosing the right product
Compared with the 14m 2.5mm 32A lead (10829), 4mm cable has a larger conductor for lower voltage drop. For 25m use the 25m 4mm 32A lead (10839).
Frequently asked questions
When do I need a 32A 110V extension lead?
Use a 32A lead only when both the outlet and the equipment are 32A, for example from the 32A outlet of a larger site transformer to a 32A splitter box or heavier machine. Most hand tools use 16A connectors.
Why choose 4mm cable?
A 4mm² conductor has lower resistance than 2.5mm², so it loses less voltage over the same length when carrying the same current.
What does IP44 mean?
IP44 means the product is protected against solid objects larger than 1mm and against water splashed from any direction. It is suitable for splashes and outdoor site use, but it is not designed to be submerged.
Not sure which cable size you need? Read our extension lead cable size guide (1.5mm vs 2.5mm vs 4mm).
Where to buy: this product is supplied in the UK by Connexion Electrical Ltd. Trade customers can log in to see prices, or use our product enquiry form for stock, quantity and delivery questions. The downloadable data sheet above lists the full technical specification.
| Product | 110V Extension Lead 14m 4mm Cable 32amp |
| Part No | 10826 |
| Safety Level | Class I |
| IP Level | IP44 |
| Safety Cetificates | Compliant |
| RoHS Directive | Compliant |
| Case | PVC + Copper for Cable, Nylon + PP for Plug/Coupler |
| Input Voltage | AC110V |
| Output Voltage | AC110V |
| Frequency | 50/60Hz |
| Input Current | 32A MAX. |
| Cable | 4.0mm 3 core PVC cable |
| Dimensions | 14m in Length |
| Color | Yellow |
| Plug | 110V 32A Plug |
| Coupler | 110V 32A Coupler |
| Packing Type | Plastic Bag + Carton Box |
| Quantity of Each Carton | 4pcs |
| Net Weight | 15KGS |
| Gross Weight | Approx.15.5KGS |
| Outer Box Dimension | 40X27X30 |
| Inner Core Colours : | Brown, Blue and Green/Yellow |
| Voltage Rating : | 300/500 Volts |
| Main Application : | Supply 110v Power to tools and lighting on site |
| Sheath Thickness mm : | 1.3mm |
| Mean Overall Diameter (upper limit) mm : | 13.0mm |
| SKU | 10826 |
| MPN | 10826 |
| GTIN | 5023003000032 |
| CERTIFICATIONS | CE, ROHS, UKCA |
